Belden 4694P 0071000 18-1 4K UHD Coax Cable, Solid Silvered Copper Conductor, RG-6, CMP, 75 Ohms, 1000' Reel, Violet

Brand: Belden
ADI #:7B-4694P0071 Model #: 4694P 0071000  Name: Belden 4694P 0071000 18-1 4K UHD Coax Cable, Solid Silvered Copper Conductor, RG-6, CMP, 75 Ohms, 1000' Reel, Violet
  • Ultra-High Definition Digital Video cable
  • Suitable for 4K Single-link 12 Gb/s UHDTV
  • Suitable for 4K D-Cinema
Image of 7B-4694P0071

Product Overview

75 Ohm SDI Coax cable, RG-6, 18 AWG Solid Silvered Copper conductor, FEP insulation, foil + 95% Tinned Copper braid shield, PVC Jacket, CMP rated.

General Information

Name : Belden 4694P 0071000 18-1 4K UHD Coax Cable, Solid Silvered Copper Conductor, RG-6, CMP, 75 Ohms, 1000' Reel, Violet , Belden
Category : Coaxial Cables
UPC Code :
Country of Origin : Mexico. Country of origin is subject to change.

Specifications

General Information

ADI Part Number : 7B-4694P0071
Brand Name : Belden
Manufacturer Part Number : 4694P 0071000
Packaged Quantity : 305

Technical Information

American Wire Gauge : 18AWG
Cable Type : RG-6
Conductor Count : 1
Conductor Material : Silvered Copper
Impedance : 75 ohms
Jacket Material : PVC-LS
Shielding : Braid
Solid or Stranded : Solid

Environmental Conditions

Operating Temperature (T-T) : 140°F

Physical Characteristics

Color : Violet
Insulation Material : FEP
Package Type : Reel

Product Information

Length : 1000'

Miscellaneous

Country of Origin : US
Indoor/Outdoor : Indoor
