Belden 5100UE 008500 14/2 FPLR Security and Commercial Audio Cable, Stranded BC, CL3R, 500' (152.4m), Gray

Brand: Belden
ADI #:7B-510050GRA Model #: 5100UE 008500  Name: Belden 5100UE 008500 14/2 FPLR Security and Commercial Audio Cable, Stranded BC, CL3R, 500' (152.4m), Gray
  • Intercom/PA Systems, Sound/Audio Systems, Fire Alarm (For color Red only)(Dual Rated)
  • Number of Element: 2
  • Size 14 AWG
Belden 5100UE 008500 14AWG Bare Copper Conductors, PP Insulation, PVC Jacket with Ripcord, Sequential Footage, 500' (152.4m), Gray

Product Overview

Security & Commercial Audio Cable, Riser-CL3R-FPLR 2-14 AWG stranded bare copper conductors with polyolefin insulation, PVC jacket with ripcord

General Information

Name : Belden 5100UE 008500 14/2 FPLR Security and Commercial Audio Cable, Stranded BC, CL3R, 500' (152.4m), Gray , Belden
Category : Plenum Audio Cables
UPC Code : 999999523833

Specifications

General Information

ADI Part Number : 7B-510050GRA
Brand Name : Belden
Manufacturer : Belden CDT, Inc
Manufacturer Part Number : 5100UE 008500
Product Name : Multi-Conductor - Commercial Audio Systems - 2 Conductors Cabled
Product Type : Audio Cable

Technical Information

American Wire Gauge : 16AWG
Cable Listing : CL3, CL3R, FPLR, FT4
Cable Rating : Plenum
Cable Type : Bare Wire
Conductor Count : 2
Device Supported : Audio Device, Audio System, Fire Alarm, Intercom, Public Address System, Sound System
Jacket Material : PVC
Shielding : No
Solid or Stranded : Stranded

Category Specific Attributes

Number of Conductors : 2

Physical Characteristics

Cable Length : 500'
Cable Length (mm) : 152400
Color : Gray
Insulation Material : Polyolefin, PP
Product Color : Gray
Product Material : Bare Copper

Miscellaneous

Environmental Certification : China RoHS, ELV, EU RoHS, EU WEEE, RoHS 2
Environmentally Friendly : Yes
Features : Stranded
