Belden 638AFS 0001000 18/3, 18/2, 18/4 and 16/4 Stranded BC Access Control Cable, Shielded, CMP, Banana Peel, 1000' (304.8m) Reel, Multicolor

Brand: Belden
ADI #:7B-638A100NT Model #: 638AFS 0001000  Name: Belden 638AFS 0001000 18/3, 18/2, 18/4 and 16/4 Stranded BC Access Control Cable, Shielded, CMP, Banana Peel, 1000' (304.8m) Reel, Multicolor
  • Unsurpassed quality and reliability
  • Robust designs that meet or exceed UL standards
  • Proven performance in installations worldwide
Image of 7B-638A100NT

Product Overview

Plenum-CMP, 3-18 AWG pairs, 4-16 AWG conductors, 4-18 AWG conductors, 2-18 AWG conductors, All conductors stranded bare copper with Flamarrest insulation, Each cable has overall Beldfoil shield and Flamarrest jacket, Banana Peel No overall jacket.

General Information

Name : Belden 638AFS 0001000 18/3, 18/2, 18/4 and 16/4 Stranded BC Access Control Cable, Shielded, CMP, Banana Peel, 1000' (304.8m) Reel, Multicolor , Belden
Category : Multiconductor Cables
UPC Code : 612825176534

Specifications

General Information

ADI Part Number : 7B-638A100NT
Brand Name : Belden
Manufacturer Part Number : 638AFS 0001000
Packaged Quantity : 305

Technical Information

American Wire Gauge : 18AWG
Cable Rating : Plenum
Conductor Count : 16
Conductor Material : Bare Copper
Number of Pairs : 3
Shielding : Yes
Solid or Stranded : Stranded

Environmental Conditions

Operating Temperature (T-T) : 167°F

Physical Characteristics

Cable Length : 1000'
Color : Blue, Gray, Orange, White
Insulation Material : PVC-LS
Package Type : Reel

Product Information

Length : 1000'

Miscellaneous

Country of Origin : MX
Indoor/Outdoor : Indoor
