Product Overview
Restaurant ? Retail ? Dance/Music Clubs ? Audio Visual ? Education ? Casinos ? Themed Entertainment ? Large System Ancillary Support ? Worship Facilities
The QSC AcousticDesign™ AD-S112sw is a low impedance, surface mounted, 12" direct radiating subwoofer. An ideal companion to AcousticDesign™ full range models, the AD-S112sw allows impressive low frequency expression within a complimenting form factor, suitable of demanding foreground and background sound reinforcement applications.
AcousticDesign™ series offers integrators a premium quality installed sound solution where performance, coverage, and aesthetics are paramount. Combined with unprecedented ease-of-installation and high weather resistance, the AcousticDesign™ series provides integrators a versatile and confident install solution.
The AD-S112sw features a high power 12" weather treated paper cone woofer on a 2.5" voice coil. TFR™ (Turbulent Flow Reduction) port design tunes the enclosure resonance and is optimized for high velocity air flow, resulting in higher output pressures before turbulence or "chuffing" of the port.
Taking full advantage of boundary plane coupling and to reduce vibration transmission, the AD-S112sw ships with an included yoke mount assembly. Additional M10 fittings on the enclosure allow suspended or flown deployments using the optional accessory M10 KIT-C.
With rugged ABS enclosures, sealed input panel covers, and powder-coated aluminum grilles for weather resistance, the AcousticDesign™ surface mounted series exceed IEC60529 IP-54 ratings for dust and splash resistance.
To further enhance performance and speed of install with optimum result, advanced voicing filter sets using QSC Intrinsic Correction™ techniques are obtainable using Q-Sys networked audio processing platforms, including CXD amplifiers for a complete QSC systems solution.
The AcousticDesign™ series feature a stylish appearance free of obtrusive logo adornments for aesthetically sensitive installations. Complimenting adjacent product families, the AD-S112sw is available in QSC standard black (RAL 9011) and may be painted to match any decor.
For your system integration needs, complete EASE, CF2, CAD, and BIM files are available for download at QSC.com
General Information
Name : QSC AD-S112SW-BK Subwoofers,AcousticDesign 12" Indoor|Outdoor,600W,Surface Mount,Black , QSC
Category : Pro Speakers
UPC Code : 999999535651
Country of Origin : China. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : QB-ADS112SWB
Brand Name : QSC
Manufacturer : QSC Audio
Manufacturer Part Number : AD-S112-SW-BK
Product Line : AcousticDesign
Product Model : AD-S112sw
Product Name : 12" Subwoofer
Product Type : Woofer
Weight (Approximate) (g) : 13154.179
Technical Information
Impedance : 8 ohms
Impedance (Ohm) : 8
Maximum Frequency Response (Hz) : 135
Minimum Frequency Response (Hz) : 30
Sensitivity : 90 dB
Sensitivity (dB) : 90
Speaker Size : 12"
Woofer Driver Material : Paper
Woofer Driver Size : 12"
Woofer Driver Size (mm) : 304.8
Audio
Maximum Frequency Response : 135 Hz
Minimum Frequency Response : 30 Hz
RMS Output Power : 600W
RMS Output Power (W) : 300
Subwoofer Type : Passive
Physical Characteristics
Color : Black
Depth : 12.70"
Depth (mm) : 322.58
Enclosure Type : Bass-Reflex
Form Factor : Surface Mount
Height : 23.4"
Height (mm) : 594.36
Package Type : Retail
Speaker Installation : Indoor|Outdoor
Weight (Approximate) : 29 lb
Width : 13.9"
Width (mm) : 353.06
Woofer Diameter : 12"
Woofer Diameter (mm) : 304.8
Miscellaneous
Environmentally Friendly : Yes
Features : 12-inch weather treated woofer, Available in black (RAL 9011), Included YMS12 yoke mount maximizes boundary plane coupling while reducing vibration transmission, Lightweight ABS enclosures offer long-term durability and lasting good looks, Maximum peak SPL 121 dB, Meets IEC60529 IP-54 for dust and splash resistance, Optional M10 Kit-C for additional installation versatility, Sealed input panel cover and powder coated aluminum grilles for added weather resistance, Suggested filter points: 32 Hz high-pass, 24 dB/octave Butterworth; 100 Hz low-pass, 24 dB/octave Butterworth, TFR (Turbulent Flow Reduction) port provides optimal resonant tuning and high velocity air flow
Package Contents : <ul> <li>12" Subwoofer</li> <li>YMS12 Yoke Mounting System</li> <li>Euroblock Connector</li> <li>Input Panel Cover</li> </ul>
