Product Overview
SoundTube SM500I-II-WX Outdoor Surface Mount Speaker in Black
SoundTube®'s WX Weather Guard technology utilizes a dual layer hydrophobic material inside the speaker grille to keep water from the drivers and internal electronics in even the most extreme weather conditions. The SM500I-II-WX utilizes the patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity as well as BroadBeam® waveguide technology to deliver a consistent dispersion pattern up to 10 kHz for maximum coverage area per speaker. The SM500I-II-WX has one 5.25 inch (133 mm) polypropylene woofer and one 1.0 inch (25 mm) convex titanium tweeter with FerroFluid™ cooling. The speakers 86.0 dB average sensitivity offers high output capabilities and reduced amplification costs and the six-position selectable tap switch for 25-, 70.7- and 100-volt applications provides easy access. The included SM500i-II-WX Stealth™ bracket mounting system with vertical and horizontal pivoting allow the SM500i-II-WX to be aimed anywhere within the installation space and the low profile enclosure design keeps the speaker close to the wall. Safety cable with speaker mounting bolt, Euroblock connector, wall mount bracket and terminal weather boot are included. IP-Rating: IP44.
General Information
Name : SoundTube SM500I-II-WX-BK Extreme Outdoor Weather Speaker with BroadBeam Tweeter, 5.25", Surface Mount, Black , SoundTube
Category : Pro Speakers
UPC Code :
Country of Origin : China. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : 9W-SM500IWXB
Brand Name : SoundTube
Manufacturer : SoundTube
Manufacturer Part Number : SM500I-II-WX-BK
Product Model : SM500I-II-WX
Product Name : SM500I-II-WX Speaker
Product Series : SMi
Product Type : Speaker
Technical Information
Crossover Type : 2-way
Impedance : 4 ohms
Sensitivity : 86 dB
Speaker Size : 5.25"
Tweeter Driver Material : Aluminum
Tweeter Driver Size : 1"
Woofer Driver Material : Polypropylene
Woofer Driver Size : 5.25"
Audio
Maximum Frequency Response : 22 kHz
Minimum Frequency Response : 60 Hz
PMPO Output Power : 150 W
RMS Output Power : 75W
Environmental Conditions
Sound Emission : 0 dB
Physical Characteristics
Color : Black
Durability : Weatherproof
Enclosure Type : Ported
Form Factor : Surface Mount, Wall Mount
Height : 11.4"
Product Color : Black
Speaker Installation : Outdoor
Product Information
Diameter : 8.4"
Installation Type : Commercial
Warranty
Limited Warranty : 5 Year
Miscellaneous
Environmentally Friendly : Yes
Package Contents : <ul> <li>SM500I-II-WX Speaker</li> <li>Euroblock</li> <li>Mounting Hardware</li> <li>Safety Cable</li> <li>Terminal Weather Boot</li> </ul>
TAA Compliant : No
