Product Overview
APC Smart-UPS XL 3000VA protects your data by supplying reliable, network-grade power with scalable run-time in tower and rack mount form factors. With optional, matching battery packs, run-time can be easily extended and optimized for the application. APC understands long run-time requirements so; Smart-UPS XL's can be configured with up to 10 additional battery packs - for run-times exceeding 24 hours, if necessary. The convergence of voice and data networks is placing higher demands on availability expectations - and the Smart-UPS XL delivers. Voice over Internet Protocol (VoIP), e-commerce, WiFi ("hotspots" , WLAN/ WWAN, and mixed wireless), and data enabled PBX's are a few of the applications driving the need for Smart-UPS XL. APC Smart-UPS XL is also the perfect UPS for fileservers (Intel or UNIX based), minicomputers, Network switches and hubs, ATM's, telecommunications systems and other mission-critical applications requiring longer runtime.
General Information
Name : APC SUM3000RMXLI2U XL Modular Smart-UPS, 3000VA, 230V , APC by Schneider Electric
Category : UPS
UPC Code :
Specifications
General Information
ADI Part Number : 2G-00RMXLI2U
Brand Name : APC by Schneider Electric
Manufacturer : Schneider Electric SA
Manufacturer Part Number : SUM3000RMXLI2U
Product Line : Smart-UPS
Product Name : Smart-UPS XL 3000VA Rack Mountable/Tower
Product Series : XL
Product Type : Line-interactive UPS
Sector : Intrusion
Weight : 103 lb
Technical Information
Number of Battery & Surge Outlets : 10
Output Voltage : 230V AC, 240V AC
Receptacle Detail : 1 x IEC 60320 C13, 4, 7 x IEC 60320 C19
Receptacle Type : IEC 60320 C13, IEC 60320 C19
Battery Information
Battery Chemistry : Lead Acid
Controls/Indicators
Status Indicators : <ul><li>Load Bar-graphs</li><li>Battery Bar-graphs</li><li>On Line</li><li>On Battery</li><li>Replace Battery</li><li>Overload</li><li>Bypass</li></ul>
Environmental Conditions
Maximum Operating Temperature : 113°F (45°C)
Thermal Dissipation : 87.92 W
Interfaces/Ports
Serial Port : Yes
Management
Alarm : Configurable Delay, Low Battery, On Battery
Physical Characteristics
Color : Black
Depth : 26.7"
Height : 3.4"
Rack Height : 2U
Width : 17"
Power Description
Input Voltage : 220V AC
Plug/Connector Type : IEC 320-C20
Surge Energy Rating : 490 J
Waveform Type : Sine Wave
Warranty
Limited Warranty : 2-Year
Miscellaneous
Environmental Certification : Green Premium, REACH, RoHS
Environmentally Friendly : Yes
Package Contents : <li>Smart-UPS XL 3000VA Rack Mountable/Tower </li><li>CD with software</li><li>Rack mounting brackets</li><li>Rack mounting support rails</li><li>Smart UPS signalling RS-232 cable</li><li>USB cable</li><li>User manual</li>
