Product Overview
Model LP4 low profile, electronic piezo sounder is a compact multi-tone sounder ideal for OEM and general alarm applications. The low voltage LP4 provides the user with the choice of 32 different tones, selectable during installation. Each electrical connection has two terminals for looping in and out, eliminating the need for a separate terminal block, making installation easier. A second tone is available if a third wire is installed and connected to the second tone terminals.
The rugged White ABS casing provides a high degree of strength and protection from the elements.
The shallow base provides for flush mount wiring, and features a unique twist assembly for easy installation. A deep base with knockouts is available as an option.
General Information
Name : Federal Signal LP4 StreamLine Low Profile Mini Sounder, PIEZO, 9-28VDC, Gray , Federal Signal
Category : Sounders
UPC Code : 782979203476
Country of Origin : United Kingdom. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : QF-LP409028
Brand Name : Federal Signal
Manufacturer : Federal Signal Corporation
Manufacturer Part Number : LP4-09-028
Product Functions : Alarm
Product Line : StreamLine
Product Model : LP4-09-028
Product Name : LP4 StreamLine Low Profile Mini Sounder
Product Type : Horn
Technical Information
Alarm Type : Audible
Connectivity Technology : Wired
Environmental Conditions
Sound Emission : 110 dB
Physical Characteristics
Application/Usage : Alarm
Color : Gray
Form Factor : Panel Mount, Surface Mount
Height : 3"
Product Color : Gray
Width : 3.7"
Power Description
Input Voltage : 28V DC
Power Source : DC
Product Information
Mount Type : Panel Mount, Surface Mount
Miscellaneous
Environmental Certification : RoHS
Environmentally Friendly : Yes
Indoor/Outdoor : Indoor, Outdoor
