Product Overview
Hikvision DS-2DF8C842IXG-ELW 8 MP 42 × Network IR Speed Dome adopts 1/1.2" progressive scan CMOS chip. With the 42 × optical zoom lens, the camera offers more details over expansive areas. This series of cameras can be widely used for wide ranges of high-definition, such as the rivers, forests, roads, railways, airports, ports, squares, parks, scenic spots, stations and large venues, etc.
General Information
Name : Hikvision DS-2DF8C842IXG-ELW DarkFighter 8MP Network IR PTZ Speed Dome Camera, 42x, Gray (Replaces DS-2DF8442IXS-AELW) , Hikvision
Category : PTZ Security Cameras
UPC Code : 842571149135
Country of Origin : China. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : HX-NPTZ8C842
Brand Name : Hikvision
Manufacturer : Hikvision
Manufacturer Part Number : DS2DF8C842IXGELW
Product Model : DS-2DF8C842IXG-ELW
Product Name : 8 MP 42 × Network IR Speed Dome
Product Type : Network Camera
Technical Information
Connectivity Technology : Wired
Effective Camera Resolution : 8MP
Field of View : Horizontal field of view: 60.4° to 1.7° (wide-tele),Vertical field of view: 36.2° to 0.9° (wide-tele),Diagonal field of view: 67.8° to 2.2° (wide-tele)
HD Recording : Yes
Lens Type : Varifocal
Maximum Aperture : f/1.6
Maximum Frame Rate : 25 fps
Minimum Focal Length : 7.50 mm
Night Vision : Yes
Night Vision Type : Infrared
Optical Zoom : 42x
Video Signal Format : NTSC, PAL
Camera
Night Vision Distance : 1640.42 ft
Wide Dynamic Range : Yes
Display & Graphics
Color Supported : Color
Maximum Video Resolution : 3840 x 2160
Environmental Conditions
Maximum Operating Temperature : 158°F (70°C)
Minimum Operating Temperature : -40°F (-40°C)
Operating Humidity : 95%
Exposure
Longest Shutter Speed : 1/1 Second
Shortest Shutter Speed : 1/30000 Second
Interfaces/Ports
Network (RJ-45) : Yes
Lens
Focal Length : 7.5-315 mm
Lens Included : Yes
Maximum Focal Length : 315 mm
Network & Communication
Remote Management : Yes
Others
ADI Part Number Replaces : HX-NOD8442XW, HX-NOD8C842
Model Number Replaces : DS-2DF8C842IXS-AELWDS-2DF8442IXS-AELW
Physical Characteristics
Color : Gray
Color Family : Gray
Durability : Dust Resistant, Impact Resistant, Vandal Resistant, Waterproof
Form Factor : Dome
Product Color : Gray
Weight (Approximate) : 21.16 lb
Power Description
Input Voltage : 24V AC
Product Information
Diameter : 10.5"
Mount Type : Pendant Mount, Pole Mount, Wall Mount
Storage
Recording Formats : 4K
Storage Type : Memory Card
Miscellaneous
Environmental Certification : REACH, RoHS, WEEE
Environmentally Friendly : Yes
Features : Built-in Microphone, Cross Line Detection, Day/Night, Human Detection, Motion Detection, Privacy Masking, SD Card Local Storage, Tampering Alarm, Vehicle Detection, Wide Dynamic Range
Impact Protection Rating : IK10
Ingress Protection Rating : IP67
TAA Compliant : No
